Premium Quality Doctor Blades

PHOTOPRINT TM

Standard Grade Carbon Steel Doctor Blade for general printing. Near perfect microstructure with evenly distributed carbon & carbides, which create desired steel for doctor blade application. Refined with minimum of non-metallic inclusions. High density steel along with enhanced mechanical & physical properties like very good hardness, tensile strength, straightness, flatness camber, edge conditions which are very essential for better & consistent printing sessions.

Ideal for general printing jobs.

Specified Lamella can be provided on customer request.

Contact Us

BONANZA TM ULTRA PLUS

LONGLIFE Carbon Steel doctor blades for critical & longer printing sessions. Near perfect microstructure with double, evenly distributed, carbon & chromium carbides (Fe, Cr) which create desired steel for doctor blade for longer printing sessions even in difficult jobs because of abrasive nature of inks & chemicals that could cause problems for smooth, long & consistent printing sessions. Refined with minimum percentage of impurities like sulphur & phosphorus, high density steel along with enhanced mechanical & physical properties like very good hardness, tensile strength, straightness, flatness, camber, edge conditions which are very essential for better & consistent printing sessions.

Ideal for long & high speed printing jobs.

BONANZA TM MMX

REMIUM GRADE STAINLESS STEEL doctor blades with very high wear resistance. Ideal for long & very high speed printing sessions. High carbon & High chromium percentage with Near perfect microstructure create steel for tough & adverse condition (Abrasive Inks) of printing jobs. Refined, high density steel along with enhanced mechanical & physical properties like very good hardness, tensile strength, straightness, flatness, camber, edge conditions which are very essential for better & consistent printing sessions.

Ideal for long printing jobs with very high speend. Very high wear resistance with moderate Corrosion Resistance.

Special Features

Material High Quality European Steel
Hardness Ideal Hardnress of 580 Hv
Tensile Strength Superior Tensile Strength of 1950-2100 Mpa
Straightness <1.0mm/3000mm
Flatness 0.2% across the width
Edges Smoothest of edges for trouble-free printing

Special Features

Blade width 8 mm - 80 mm
Blade thickness 0.10 t0 0.30 mm

Lamella Processing

Optimized process to produce Superior Quality of blades with near zerp thermal damage.
